| 1 inch gasoline water pump | |||
| Set | Model | WP10A | WP10B |
| Name | Gasoline self-priming pump | ||
| Inlet/Outlet diameter | 25mm(1") | 25mm(1") | |
| Cont. Capacity(m3/h) | 7 | 7 | |
| Cont. Head lift(m) | 22 | 22 | |
| Max.Suction head(m) | 7 | 7 | |
| Engine | Engine model | 1E40F | 1E40F-5A |
| Engine type | Single cylinder,2-stroke,air cooled gasoline engine | ||
| BorexStroke(mm) | 40x34 | 40x34 | |
| Displacement(ml) | 42.73 | 42.73 | |
| Compression ratio | 7.66:1 | 7.66:1 | |
| Max.output power(HP) | 1.5 | 1.5 | |
| Rated spee(RPM) | 6500 | 6500 | |
| Fuel consumption ratio(g/kw.h) | <610 | <610 | |
| starting method | Recoil start | ||
| Gasoline and oil mix rate | 25:1 | 25:1 | |
| Fuel tank capacity(L) | 1.2 | 1.2 | |
| Pack | Packing size(mm) | 310x295x315 | 310x295x315 |
| Net weight(Kgs) | 7.6 | 8 | |
| Gross weight(Kgs) | 8 | 9 | |
| 20FT Qty | 931 | 931 | |
Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet
Gasoline engine driven water pump
1 inch Gasoline self-priming Water Pump
1 inch Gasoline self-priming Water Pump Parameter 1 inch gasoline water pump Set Model WP10A WP10B ...
ISO9001 Supplier
Class Certificate
Export Supply
Key Highlights
Category
Gasoline engine driven water pump
Standard
EN
Weight / Size
Head lift(m) 22 22 Max.Suction head(m) 7 7 Engine Engine model 1E40F 1E4...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.
Technical Specifications
Category
Gasoline engine driven water pump
Model / SKU
1-inch-Gasoline-self-priming-Water-Pump
Standard
EN
Weight / Size
Head lift(m) 22 22 Max.Suction head(m) 7 7 Engine Engine model 1E40F 1E40F-5A Engine type Single cylinder,2-stroke,air cooled gasoline engine BorexStroke(mm) 40x34 40x34 Displacement(ml) 42.73 42.73 Compression ratio 7.66:1 7.66:1 Max.output power(HP) 1.5 1.5 Rated spee(RPM) 6500 6500 Fuel consumption ratio(g/kw.h) <610 <610 starting method Recoil start Gasoline and oil mix rate 25:1 25:1 Fuel tank capacity(L) 1.2 1.2 Pack Packing size(mm) 310x295x315 310x295x315 Net weight(Kgs) 7.6 8 Gross weight(Kgs) 8 9 20FT Qty 931 931
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
