Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet

Pump Motor And Accessories

8L Accumulator Tank

8L Accumulator Tank Pressure tank in the constant pressure water supply system to play a constant role in the pressure to prevent the system pressure fluctuated to reduce the frequent start of the pump ...

ISO9001 Supplier Class Certificate Export Supply
8L Accumulator Tank

Key Highlights

Category
Pump Motor And Accessories
Standard
EN
Weight / Size
Pressure Inlet/outlet size Net Weight SFAT-087-021-01 8L 87 PSI(6 Bar) 3...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Category
Pump Motor And Accessories
Model / SKU
8L-Accumulator-Tank
Standard
EN
Weight / Size
Pressure Inlet/outlet size Net Weight SFAT-087-021-01 8L 87 PSI(6 Bar) 3/4" MNPT 2KG DIMENSIONS
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
Contents
  1. 8L Accumulator Tank
  2. STANDARD PUMP CONFIGURATIONS
  3. DIMENSIONS

8L Accumulator Tank

Pressure tank in the constant pressure water supply system to play a constant role in the pressure to prevent the system pressure fluctuated to reduce the frequent start of the pump can also be used to absorb the system due to valves, pumps and other open and off caused by water hammer impact, pressure The tank can be a small amount of water at night to make the main water pump system sleep to reduce electricity consumption, extend the pump life. Pressure tank in the air conditioning, to warm, solar, boilers and other closed water circulation system can be stable pressure, to avoid frequent opening of the safety valve and automatic replenishment valve frequent water and so on.

STANDARD PUMP CONFIGURATIONS

Model Tank Volume

Max. Pressure

Inlet/outlet size

Net Weight

SFAT-087-021-01 8L 87 PSI(6 Bar) 3/4" MNPT

2KG

DIMENSIONS

8L Accumulator Tank
