The instrumentation is used to monitor various thermodynamic parameters, such as, liquid level, temperature, pressure, flow, etc.
Working voltage: DC18~DC28V
Input signal: 4～20mA
Display range: 0.00～99.99
Communication interface: RS485
Installation: flush type
Power consumption: <10W
Output relay capacity: <10W, 220VAC/2A
Manpower failure alarm
RS485 interface for telecontrol
Extend function for key
Setting for Main alarm, pre-alarm, measuring range of various channel
Approved by classification societies
"Slope" and "nil leaning" setting by Software, Correction technique w/o POT
Monitor analog signal, with followed function: Sensor failure alarm, system fault alarm, and direct alarm, pre-alarm
Max monitoring point: 8points (RDCP6); 15Points
Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet
Monitoring And Alarming Device
RDCP Series Intelligent Instrumentation
The instrumentation is used to monitor various thermodynamic parameters, such as, liquid level, temperature, pressure, flow, etc. Working voltage: DC18~DC28V Input signal: 4～20mA Display range: 0.00～99.99 Communica...
ISO9001 Supplier
Class Certificate
Export Supply
Key Highlights
Category
Monitoring And Alarming Device
Standard
EN
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.
Technical Specifications
Category
Monitoring And Alarming Device
Model / SKU
RDCP-Series-Intelligent-Instrumentation
Standard
EN
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
