RDLM Series Level Monitoring and Alarm System

RDLM-04-LS Cargo Hold High Level/overfill Alarm System

The system is designed using the magnetic float switch principle which has been proven very Effective. Each system consists of the float switch and alarming panel. Reed switches inside the stem Are activated by the per...

ISO9001 Supplier Class Certificate Export Supply
RDLM-04-LS Cargo Hold High Level/overfill Alarm System

Key Highlights

Category
RDLM Series Level Monitoring and Alarm System
Standard
EN
Certificate
CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Category
RDLM Series Level Monitoring and Alarm System
Model / SKU
RDLM-04-LS-Cargo-Hold-High-Level-overfill-Alarm-System
Standard
EN
Certificate
CCS
Warranty
12 Months unless specified otherwise
Origin
China

China RDLM-04-LS Cargo Hold High Level/overfill Alarm System:

The system is designed using the magnetic float switch principle which has been proven very
Effective. Each system consists of the float switch and alarming panel. Reed switches inside the stem
Are activated by the permanent magnetic inside the float which rises and falls with the changes of liquid
Level. Once the reed switch is activated, it sends an alarm signal to the indicating unit in the control
Room.

Monitor liquid level for various tank, cabinet and water tank. Also, be used in cargo high alarm/overfill
Alarm for oil tank, chemical tanker, LPG and so on.

Tech. Spec.

Power supply: AC220V/50Hz, AC110V/60Hz
Operating temperature: -10 +90degree
Medium density: >0.5g/cm3
Protection degree: IP56
Ex marking: Exira II CT6

Type approval: CCS, GL, NK

Characteristic

Simulate the position of over liquid level through the pull rod of level sensor
Advanced technology, self-checking, loop failure monitoring
