The instrumentation is used for monitoring various parameters, such as, liquid level, pressure,
Temperate for one piece of cargo tank. It can monitor 1channel level, 1channel pressure, and 3 channels
Temperate. Each channel can be set different High/lowalarmvalue.
Working power: DC18V～DC28V
Input signal: 4～20mA(level/pressure),PT100(temp.),RS485(level/press./temp.)
Measuring range: Level0000～9999(adj.),temp.0000~0999(adj.), press.-9999~9999(adj.)
Relay output: sound alarm, low/high alarm, fault alarm
Extend alarm: extend level alarm
Failure alarm: <2mAor >30mA
Overall size: 75W×158H×88L (mm)
Cutout size: 75W×150H (mm)
Inner self-checking, sensor failure monitoring
Display in digit Ron, set various index
Set high alarm or low alarm, alarm output
RS485 interface for telecontrol
"Full range" or "zero" adjustment w/o POT
Approved by classification societies
Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet
Monitoring And Alarming Device
RDYB-205 Intelligent Instrumentation
The instrumentation is used for monitoring various parameters, such as, liquid level, pressure, Temperate for one piece of cargo tank. It can monitor 1channel level, 1channel pressure, and 3 channels Temperate. Each ch...
ISO9001 Supplier
Class Certificate
Export Supply
Key Highlights
Category
Monitoring And Alarming Device
Standard
EN
Weight / Size
30mA Overall size:
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.
Technical Specifications
Category
Monitoring And Alarming Device
Model / SKU
RDYB-205-Intelligent-Instrumentation
Standard
EN
Weight / Size
<2mAor >30mA Overall size:
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
