Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet

Gear Pump

WCB Series Gear Pump Marine

WCB-type gear oil pump belongs to a low pressure micro-portable energy-efficient pump, suitable for flats for sale without motive power switch to oil barrels, also applies to oil refineries, power plants, power plants...

ISO9001 Supplier Class Certificate Export Supply
WCB Series Gear Pump Marine

Key Highlights

Category
Gear Pump
Standard
CB
Weight / Size
Main Specification Type Capacity Pressure Oil Height Head Voltage Speed ...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Category
Gear Pump
Model / SKU
WCB-Series-Gear-Pump
Standard
CB
Weight / Size
Main Specification Type Capacity Pressure Oil Height Head Voltage Speed Power Access caliber Weight Size (l/min) (MPa) (m) (m) (V) (r/min) (kW) (mm) (kg) L B H WCB-30 30 0.3 5 30 220 2800 0.37 20 14.5 390 196 220 WCB-50 50 0.3 5 30 220 2800 0.55 25 14.5 400 210 220 WCB-75 75 0.3 4 30 220 2800 0.75 25 15 420 230 230 WCB1-75 75 0.3 4 30 380 2800 0.75 25 15 420 230 230 Note:
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China

China WCB Series Gear Pump Marine:

WCB-type gear oil pump belongs to a low pressure micro-portable energy-efficient pump, suitable for flats for sale without motive power switch to oil barrels, also applies to oil refineries, power plants, power plants, transformer substation (room) and the oil depot .

Main Specification

Type Capacity Pressure Oil Height Head Voltage Speed Power Access caliber Weight Size
(l/min) (MPa) (m) (m) (V) (r/min) (kW) (mm) (kg) L B H
WCB-30 30 0.3 5 30 220 2800 0.37 20 14.5 390 196 220
WCB-50 50 0.3 5 30 220 2800 0.55 25 14.5 400 210 220
WCB-75 75 0.3 4 30 220 2800 0.75 25 15 420 230 230
WCB1-75 75 0.3 4 30 380 2800 0.75 25 15 420 230 230

Note: 380V technical parameters remain unchanged

Type:

WCB: Gear Pump

75: Capacity 75L/min
