Water Jet Propulsion

ZPT300-26 Axial Flow Propulsion Pump

  ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other boats for propulsion device to ...

ISO9001 Supplier Class Certificate Export Supply
ZPT300-26 Axial Flow Propulsion Pump

Key Highlights

Category
Water Jet Propulsion
Standard
EN
Weight / Size
  ZPT type axial flow water pump jet is suitable for taxi boat, lateral ...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Category
Water Jet Propulsion
Model / SKU
ZPT300-26-Axial-Flow-Propulsion-Pump
Standard
EN
Weight / Size
  ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other boats for propulsion device to use.
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China

China ZPT300-26 Axial Flow Propulsion Pump:

ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other boats for propulsion device to use. The pump can choose motor drive,hydraulic pressure drive or diesel engine drives and other three ways.

Main Technical Data
Model Flow rate
Q（m³/h） 		Lift
H (m) 		Rev speed
r/min 		Outlet diameter
(mm)
ZPT200-26 320 26 1460 138
ZPT250-26 500 26 1460 188
ZPT300-26 720 26 1460 220
ZPT350-24 1000 24 1460 250
ZPT400-24 1380 24 980 268
ZPT450-24 1600 24 980 300
ZPT500-26 2200 26 980 360
ZPT600-26 2600 26 730 460
ZPT700-28 4860 28 730 520
ZPT800-28 6200 28 585 600
ZPT900-30 7600 30 585 720
ZPT1000-28 12000 28 585 800
