Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet

Valve Remote Control System

EHP-S Single-acting Mini Hydraulic Pump Unit

The device is connected with single-acting actuator and used as a micron hydraulic power unit to provide the hydraulic power to control the open/close valve. Working pressure: 8MPa Motor voltage: AC220V, AC380V Volume...

ISO9001 Supplier Class Certificate Export Supply
EHP-S Single-acting Mini Hydraulic Pump Unit

Key Highlights

Category
Valve Remote Control System
Standard
ISO
Certificate
CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Category
Valve Remote Control System
Model / SKU
EHP-S-Single-acting-Mini-Hydraulic-Pump-Unit
Standard
ISO
Certificate
CCS
Warranty
12 Months unless specified otherwise
Origin
China

China EHP-S Single-acting Mini Hydraulic Pump Unit:

The device is connected with single-acting actuator and used as a micron hydraulic power unit to provide the hydraulic power to control the open/close valve.
Working pressure: 8MPa
Motor voltage: AC220V, AC380V
Volume flow: 1.5L/min, 5L/min
Hydraulic oil: ISO HM32
Control voltage: 24VDC
Ambient temp: -15℃~ +60℃
Oil outlet interface: M14×1.5
Max. Oil capacity of actuator: 3.4L
Max. Outline: 460×310×290(mm)
Protection: IP6
