Marine Kitchen Galley

Marine DZG60Q9D Electric Boiling Pan (Tilting type)

Marine DZG60Q9D Electric Boiling Pan (Tilting type) 1.The main material of the machine is constructed with food grade SUS 304 stainless steel, and it's with simple and generous appearance; 2.The machine ...

ISO9001 Supplier Class Certificate Export Supply

Key HighlightsCategory
Marine Kitchen Galley
Standard
EN
Material
Marine DZG60Q9D Electric Boiling Pan (Tilting type) 1.The main material ...
Weight / Size
Model Power supply (V/Hz) Power (kW) Nominal volume (L) Working pressure...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.

Technical Specifications

Marine DZG60Q9D Electric Boiling Pan (Tilting type)

1.The main material of the machine is constructed with food grade SUS 304 stainless steel, and it's with simple and generous appearance;

2.The machine is with advanced technology, reliable quality, it's easy to use and maintenance; in addition, it's intellectualized, energy-saving, effective and real-time management is also can be achieved;

3.The temperature time controller is adopted, heat preservation, water shortage protection and presure and other functions are available; It's also with design of parameterized setting, push-to-start, electric or manual tilting (for your option), failure display alarm, running state display etc;

4.It's equipped with high configuration large super high-definition display, which shows real-time working status and a warning signal can be sent when it needs maintenance.

Techincal data:

Model	Power supply (V/Hz)	Power (kW)	Nominal volume (L)	Working pressure (MPa)	Water interface	Incoming line interface	Dimension (mm)
DZG60Q9D	3～220/60 3～380/50 3～440/60 3～480/60	9	60	≤0.2	DN15	PG21	(W×DxH) 990×640×800
