1 inch Gasoline self-priming Water Pump

Request a Quote Not what you need, please send your RFQs via Email.

Details

1 inch Gasoline self-priming Water Pump

Parameter

1 inch gasoline water pump
Set Model WP10A WP10B
Name Gasoline self-priming pump
Inlet/Outlet diameter 25mm(1") 25mm(1")
Cont. Capacity(m3/h) 7 7
Cont. Head lift(m) 22 22
Max.Suction head(m) 7 7
Engine Engine model 1E40F 1E40F-5A
Engine type Single cylinder,2-stroke,air cooled gasoline engine
BorexStroke(mm) 40x34 40x34
Displacement(ml) 42.73 42.73
Compression ratio 7.66:1 7.66:1
Max.output power(HP) 1.5 1.5
Rated spee(RPM) 6500 6500
Fuel consumption ratio(g/kw.h) <610 <610
starting method Recoil start
Gasoline and oil mix rate 25:1 25:1
Fuel tank capacity(L) 1.2 1.2
Pack Packing size(mm) 310x295x315 310x295x315
Net weight(Kgs) 7.6 8
Gross weight(Kgs) 8 9
20FT Qty 931 931
