According the requirement of SOLAS, the cargo should be equipped with a system to monitor possible
In cargo hold. When the cargo hold fire, the fan unit aspirate the generated smoke to main...
According the requirement of SOLAS, the cargo should be equipped with a system to monitor possible In cargo hold. When the cargo hold fire, the fan unit aspirate the generated smoke to main alarm panel Through CO2 pipeline and complex cross valve. When smoke concentration exceeds the set value, main Alarm panel emit an alarm and send the alarm to repeater unit in navigation room for reminding staff on Duty to prompt deal with.
Technical Specification
A main alarm panel, or a main alarm panel with extension panel One or more repeater unit, installed in navigation room or others, for remotely display and alarm A fan unit for aspirating sampler from cargo hold.
Power: AC220V/230V 50Hz/60Hz (Main power); AC220V/230V 50Hz/60Hz (Backup) Monitored channel: 4, 6 or 8 Protection class: IP44 Working temp.: 0~+55℃
