DWS305 SOLAR LED 3NM Barge Navigation Light

The Solar LED Barge Navigation Light DWS305/3NM is specially designed for the navigation safety of the non-powered seagoing vessels such as Barge, Dredger or Tug boats etc.. This LED barge l...

Marine LED Light5 Photos ISO9001 Supplier

DWS305 SOLAR LED 3NM Barge Navigation Light

Category: Marine LED Light
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty: 12 Months unless specified otherwise
Place of Origin: China

We can supply according to your requirement.

China DWS305 SOLAR LED 3NM Barge Navigation Light:

The Solar LED Barge Navigation Light DWS305/3NM is specially designed for the navigation safety of the non-powered seagoing vessels such as Barge, Dredger or Tug boats etc.. This LED barge light complies with COLREGS(1972) ,UL 1104 and EN 60945(2002) standards, with a visibility of more than 3 Nautical Miles and an autonomy 120 hours. It has the characteristics of solar self-contained, durable ,anti-UV & easy-installation. The boat signal light can be easily installed on vessels without cable and professional training.

RELIABLE AND STEADY FOR MARINE ENVIRONMENT

Steady-on and its visibility: 3NM Solar panel 1.5Wp, replaceable Ni-HM battery 4.8Ah.

Light Output : 112.5°Port/Starboard;135°Stern;225° Masthead.

UNIQUE DESIGN AGAINST DIFFICULT CONDITION

Charge under nearly all weather conditions and up to 120 hrs of operating capacity from a full charge. Individual dome can

protect the solar panel and raise its efficiency. Lens is polycarbonate with anti-UV which is produced by Bayer.

LOW MAINTENANCE

Turns on at dusk and off at dawn automatically. Completely self-contained.

MANUFACTURED TO ISO9001:2015 QAS AND CERTIFIED CE Conform to latest international standard

Light Output Steady-on
Average Intensity White 26cd
Red 24cd
Green 25cd

Amber
20cd
Visibility 3NM
Horizontal Output 112.5,135,225,360 degree
LED 4 pieces
Minimum Autonomy 120 Hours
Latitude Range 55 degree S to 55 degree N
On/Off Level 60/100Lux
Lifespan of LEDS Up to 50 000 Hours
Solar Panels Mono-crystalline,Maximum power 1.5w,Efficiency 20%
Battery Ni-MH,Replaceable 4.8AH
Construction

Lens Material
Polycarbonate
Colored Lens Option
Red green amber white blue
Control Methods PWM+Adaptive control algorithm
Mounting Option 4 bolts or Magnetic base
Weight/Demmsion
0.9Kg/166mmx166mmx166mm
Environment
Temperature Range -40°Cto +80°C
Waterproof IP67
