Marine Equipment
Free Fall Lifeboat
Product Description: Free fall lifeboat is the type the embarkation at the aft hatch,its building is according to the latest regulations of SOLAS and rules of international lifesaving ...
PDF Datasheet
Product Description:
Free fall lifeboat is the type the embarkation at the aft hatch,its building is according to the latest regulations of SOLAS and rules of international lifesaving equipments(LSA),Revision bill of MSC.218(82),MSC.275(85) and resolutions of MSC.81(70),Revision bill of MSC.226(82),MSC.274(85).
It can safely evacuate crew from vessels or offshore platforms upon the slipways.The free fall release systems are specifically designed for easy activation by the crew. Very safe and reliable.
Feature:
1.Class certificates:ABS, BV, CCS, DNV, EC, GL, LR, NK, etc.
2.Capacity:20-44 persons
Material:
The hull/canopy of lifeboat is made of the fire reinforced plastic(F.R.P.—fire retardant ). The spacebetween the inside and outside hull/canopy is filled with polyurethane foam which will supply sufficient buoyancy for the boat. The boat will be afloat with the help of the foam even the part of boat underneath the water damaged.The fully loaded boat will be self-righting when the boat turn over to any angle. This lifeboat Equipment is used for the life-saving and rescue on the sea.
Specification:
| Type | Passenger（p） | Main dimensions(m) | Permitted height(m) | Rating landing angle | Host/Power(kw) | Empty boat weight(kg) | Full load boat weight(kg) |
| BCFC-5.2M | 20 | 5.20×2.50×3.07 | 16 | 35° | 380J-3/20.6 3JH30A/22.1 DV29/21.3 | 2615 | 4265 |
| BCFF-5.2M | 20 | 5.20×2.50×3.07 | 16 | 35° | 2955 | 4605 | |
| BCFC-6.0M | 28 | 6.00×2.62×3.08 | 16 | 35° | 3182 | 5492 | |
| BCFF-6.0M | 28 | 6.00×2.62×3.08 | 16 | 35° | 3520 | 5830 | |
| BCFC-6.8M | 32 | 6.80×2.75×3.10 | 20 | 35° | 3530 | 6170 | |
| BCFF-6.8M | 32 | 6.80×2.75×3.10 | 20 | 35° | 3840 | 6480 | |
| BCFC-9.0M | 44 | 9.00×2.80×3.33 | 22 | 35° | 4900 | 8530 | |
| BCFF-9.0M | 44 | 9.00×2.80×3.33 | 22 | 35° | 5250 | 8880 | |
| BCFC is common type,BCFF is fire-resistant type. Other choices for the engine: Three imported engines are available. SABB(21.6KW) , BUKH(21.3KW) and Yanmar(22.1KW) . | |||||||
