Marine CY-2A 15ppm Bilge Alarm System

CY-2A 15ppm bilge alarm system is a new-type instrument for monitoring micro-oil content in waste water and has many new functions, like real time monitor flow, SD card storage, LCD screen display, etc. It's suitable for continuous monitoring of the oily water discharge in the bilge, with a 15 overrun alarm system and a controlling system for waste water discharge. In most case, it applied as a matching device for oil water separator. CY-2A can also be used in oilfield, chemical industry, etc.

The instrument has passed CCS (Certificate of Type Approval) Certification, and meets relevant specification requirements of IMO.RES.MEPC.107(49).

The whole machine use modularization design, stable performance, convenient for installation and maintenance.

Add flow monitor function.(according to MEPC10749 resolution)

LCD display, content diversity; interface intuitive, more humanized.

Using SD card (2 GB) storage technology, solve storage capacity limited, more humanized.

The machine with RS232 gorge line communication connector. It’s convenient for transmission data with computer.

4-mA current output connector.

The machine has storage data query function.

The machine has two print way: current print and history print, the output of data could be more intuitive and clear.

The machine with auto-clean function.

Small in size, light in weight, convenient for installation.
