Tugboat Type Rubber Fender
It is typically mounted on the bow,stern and both sides of a towboat or push boat.It can effectively counterpart the impact force between the ship and the dock and that between ships.hen...
Loading product images...
Tugboat Type Rubber Fender
PDF Datasheet
We can supply according to your requirement.
China Tugboat Type Rubber Fender:
It is typically mounted on the bow,stern and both sides of a towboat or push boat.It can effectively counterpart the impact force between the ship and the dock and that between ships.hence,it is ideal for preventing boats as well as dock, etc. from being damaged by the impact force.
Feature:
This ship rubber fender is ideal for various towboat and push boat protection.
It can be mounted onto dock,bow, stern and both sides of a towboat or push boat,thus allowing the boats to perform towing and pushing in safe conditions.
Designed in an intergral structure,the rubber fender offers reliable performance and it is easy for installation.
Size:
Specification:
| Specification | |||||||||||
| ΦD | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 700 | 800 | 900 | 1000 |
| L | 2-13 meters in one section or joined for longer lengths | ||||||||||
| A | 150 | 200 | 225 | 250 | 300 | 350 | 350 | 350 | 350 | 350 | 350 |
| B(max) | 530 | 570 | 600 | 630 | 670 | 730 | 800 | 860 | 930 | 1000 | 1060 |
| C | 500 | 500 | 700 | 800 | 800 | 900 | 900 | 1000 | 1000 | 1100 | 1200 |
| E | Varies in width,according to size and type of circumferential attachment | ||||||||||
| ΦG | 150 | 190 | 225 | 260 | 300 | 375 | 450 | 525 | 600 | 675 | 750 |
| ΦD | 100 | 125 | 150 | 175 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
| Φj | 75 | 75 | 75 | 100 | 100 | 100 | 125 | 125 | 125 | 150 | 150 |
