Alarm Indicator Column

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

China Alarm Indicator Column:

Alarm Indicator Column

1)Chapter 2 of Part 4 of the"Steel Ship Classification Rules" of the China Classification Society:
2)IMO resolution A.1021 (26) code on alerts and indicators,2009.

NO. Type Colour Shell material Cable gland IP rating Power consumption Alarm sound level
1 SG-6/2 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
2 SG-6/3 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
3 SG-7/2 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
4 SG-7/3 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
5 SG-8/2 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
6 SG-8/3 White RAL7035 Q235B 2xM25x1.5 IP44 30 100-120
