Anchor(Bow) Shackle (With Square Head Pin),SS304 OR SS316 CSXK13
- Category:Shackle
- Material:Stainless steel
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Anchor(Bow) Shackle (With Square Head Pin),SS304 OR SS316 CSXK13:
-SHACKLE(WITH-SQUARE-HEAD-PIN),SS304-OR-SS316-CSXK13-1.jpg)
| SIZE |
B mm |
A mm |
C mm |
D mm |
SWL kgs |
BL kgs |
| 4 | 4 | 8 | 18 | 15 | 138 | 550 |
| 5 | 5 | 10 | 23 | 17 | 300 | 1200 |
| 6 | 6 | 12 | 27 | 21 | 425 | 1700 |
| 8 | 8 | 16 | 37 | 28 | 625 | 2500 |
| 10 | 10 | 20 | 46 | 35 | 1075 | 4300 |
| 12 | 12 | 24 | 55 | 42 | 1550 | 6200 |
| 13 | 13 | 26 | 60 | 45 | 1585 | 6340 |
| 14 | 14 | 28 | 63 | 50 | 1625 | 6500 |
| 16 | 16 | 32 | 74 | 56 | 1750 | 7000 |
| 19 | 19 | 38 | 87.5 | 66 | 3500 | 14000 |
| 22 | 22 | 44 | 99 | 76 | 4250 | 17000 |
| 25 | 25 | 50 | 112.5 | 87 | 5000 | 20000 |
| 28 | 28 | 56 | 126 | 98 | 5000 | 20000 |
