FA20-3D00SB7 Offshore Wind Vane
- Category:Life-Saving Light
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China FA20-3D00SB7 Offshore Wind Vane:
The FA20 series is a maintenance-free offshore wind direction sensor that utilizes special salt mist corrosion resistant bearings and aluminum alloy hard anodizing technology. This ensures accurate wind measurement in harsh environments such as C5-M corrosion and sandstorms. It is characterized by high measurement accuracy, strong wind resistance, corrosion resistance,
and wear resistance. The design features optimized straight-through and staggered labyrinth structures,achieving non-contact sealing design and ensuring IP66 protection performance. It is suitable for industries such as wind power generation, railways, highways,meteorological monitoring for ships, and disaster prevention systems, providing reliable wind direction
measurement data.
Product Features
Non-contact magnetic measuring technology for high precision wind data and strong anti-interference
Optimized direct-through and staggered labyrinth design for IP66 protection
Metal housing ensures excellent corrosion resistance for harsh industrial environments
Corrosion-resistant bearings suitable for C5-M marine conditions
Fault-tolerant design provides protection against damage
With lightning surge protection circuit
Maintenance-free design reduces maintenance costs
Electrical
Operating voltage 12-30VDC
Power consumption 1W @ 24VDC
Signal output 4-20mA
Measuring principle Noncontact magnetic scanning
system
Cable 6-core shielded cable with M16
circular connector(female)
Wiring M16 circular connector(male)
ESD IEC61000-4-2
Contact Discharge±8kV,Air Discharge±15kV
Surge IEC61000-4-5 L-L ±4kV
Senor
Measuring range 0~360°
Accuracy ±2°
Resolution 0.35°
Starting threshold 0.5m/s @ 20℃
Anti-wind leve l75m/s hold for 30 s
Mechanical
Housing color Metallic
Housing material Aluminium alloy
Wind vane material Aluminium alloy/SUS304
Surface finishing Hard anodizing
Weight 0.4kg
Mounting Threaded mount G3/4
Operating temperature -40˚C ~ +70˚C
Storage temperature -40˚C ~ +80˚C
Operating humidity 0~100%RH
Vibration resistant rate IEC60068-2-6 2g
IP rate IEC60529 IP66
Salt spray rate ISO9227 NSS 1440h
