HNF-A Throw Over Board Inflatable Liferaft
The throw over board inflatable liferaft is stowed in the container on the deck. Pulling the painter line,the liferaft inflates in the water. Specification:6 persons, 10 persons, 15 pe...
HNF-A Throw Over Board Inflatable Liferaft
PDF Datasheet
We can supply according to your requirement.
China HNF-A Throw Over Board Inflatable Liferaft:
The throw over board inflatable liferaft is stowed in the container on the deck. Pulling the painter line,the liferaft inflates in the water.
Specification:6 persons, 10 persons, 15 persons, 20 persons and 25 persons.
| Model | Capacity (person) | Maximum Stowage height (m) | SOLAS A PACK | SOLAS B PACK | ||
| Weight (kg) | Dimension of container (mm) | Weight (kg) | Dimension of container (mm) | |||
| HNF-A6 | 6 | 36 | 78 | Φ580×1100 | 61 | Φ550×1100 |
| HNF-A10 | 10 | 97 | Φ600×1260 | 70 | Φ580×1100 | |
| HNF-A15 | 15 | 130 | Φ660×1300 | 92 | Φ600×1200 | |
| HNF-A20 | 20 | 157 | Φ680×1400 | 108 | Φ600×1300 | |
| HNF-A25 | 25 | 182 | Φ700×1400 | 125 | Φ680×1400 | |
Approval:CCS And EC.
CCS Specific Standard:
MSC,81(70) revised recommendation on life-saving appliances and MSC.226(82) ,MSC.295(87),MSC.323(89),MSC.48(66) the international life-saving appliance code and MSC.212(82),MSC.293(87) 1998 Amendment to the international convention for the safety of life at sea,1974
EC Specific Standard:
SOLAS 74 as amended Reg.III/4,13,21,26,31,34,Reg X/3
MSC,48(66) LSA Code, MSC/Circ.811 1994 and 2000 HSC code 8, IMO Res. MSC 81(70),
MSC/Cir.980,MSC.218(82),MSC,226(82)/,MSC.295(87), MSC/Circ.811, ISO 15738(2002)
