Marine Screw Compressor

Request a Quote Not what you need, please send your RFQs via Email.

Details

China Marine Screw Compressor:

1. The motor is a marine motor.

2. The control system is a marine control system.
3. Different certificates will be available, such as CCS, ABS, BV, LR, GL, RINA, etc.

Advantages

1.The unit area is small, easy installation and convenience.
2.The unit is easy to operate with low noise.
3.The unit is equipped with pressure, temperature, overloading and other multiple protection, to ensure safe and reliable operation of compressor.

Main Technical Specifications

Type Displacement Pressure Power Cooling Outline size Weight
(m3/min) (MPa) (kW) method (mm) (kg)
LGFD-1.4/7-C 1.4 0.7 11 Air 1130×890×1170 720
LGFD-1.7/8-C 1.7 0.8 15 Air 1130×890×1170 740
LGFD-1.4/10-C 1.4 1 15 Air 1130×890×1170 740
LGFD-2.5/8-C 2.5 0.8 18.5 Air 1130×890×1170 750
LGFD-2.2/10-C 2.2 1 18.5 Air 1130×890×1170 760
LGFD-3/8-C 3 0.8 22 Air 1130×890×1170 760
LGFD-2.8/10-C 2.5 1 22 Air 1130×890×1170 760
LGFD-2.4/12-C 2.4 1.2 22 Air 1130×890×1170 760
LGFD-3.8/8-C 3.8 0.8 30 Air 1180×1100×1470 950
LGFD-4.5/8-C 4.5 0.8 30 Air 1180×1100×1470 950
LGFD-3.8/10-C 3.8 1 30 Air 1180×1100×1470 950
LGFD-6/8-C 6 0.8 37 Air 1180×1100×1470 1000
LGFD-4.5/10-C 4.5 1 37 Air 1180×1100×1470 1000
LGFD-6.5/8-C 6.5 0.8 45 Air 1180×1100×1470 1050
LGFD-5.5/10-C 5.5 1 45 Air 1180×1100×1470 1050
LGFD-4.9/12-C 4.9 1.2 45 Air 1180×1100×1470 1050
SDW75-C 12 0.8 75 Water 2094×1440×1570 2000
CSDW90 12 1 90 Water 2094×1440×1570 2100
CSDW90 14 0.8 90 Water 2094×1440×1570 2100
CSDW110 16.5 0.8 110 Water 2600×1550×1600 2600
SDW132-C 16.5 1 132 Water 2600×1550×1600 2800
CSDW132 20 0.8 132 Water 2600×1550×1600 2600
CSDW160 20 1 160 Water 2600×1550×1600 2800
CSDW200 30 0.8 200 Water 3500×2000×2000 4500
CSDW250 30 1 250 Water 3500×2000×2000 5000
CSDW250 36 0.8 250 Water 3500×2000×2000 4700
CSDW315 36 1 315 Water 3500×2000×2000 5300
