Marine YSZ-5.0 15ppm Big Oily Water Separator
- Category:Marine Oil Water Seperator
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
Marine YSZ-5.0 15ppm Big Oily Water Separator
|
Model Parameter |
YSZ-0.1 | YSZ-0.25 | YSZ-0.5 | YSZ-1 | YSZ-1.5 | YSZ-2 | YSZ-3 | YSZ-4 | YSZ-5 | ||
|
(m³/h) Capacity |
0.1 | 0.25 | 0.5 | 1.0 | 1.5 | 2.0 | 3.0 | 4.0 | 5.0 | ||
|
Discharging standard |
≤15ppm(IMO)MEPC.107(49) ≤15ppm satisfy(IMO)MEPC.107(49) |
||||||||||
|
Working pressure |
≤0.3MPa | ||||||||||
|
Plunger pump |
Model |
DZ-100 | DZ-250 | DZ-500 | DZ-1000 | DZ-1500 | DZ-2000 | DZ-3000 | DZ-4000 | DZ-5000 | |
|
(m3/h) Capacity |
0.1 | 0.25 | 0.5 | 1.0 | 1.5 | 2.0 | 3.0 | 4.0 | 5.0 | ||
|
(MPa) Discharging pressure |
0.3 | ||||||||||
|
(m) Suction lift |
6 | ||||||||||
|
(kw) Motor power |
0.12 | 0.18 | 0.25 | 0.37 | 0.75 | 0.75 | 1.1 | 1.5 | 1.5 | ||
|
（kw) Electricheating power |
- | 1 | 2 | 2~3 | 3~5 | ||||||
|
Power supply |
3Ph/380V/50Hz;& 3Ph/440V/60Hz; | ||||||||||
|
Control mode |
Automatic | ||||||||||
|
Oil-discharge mode |
Automatic/Manual | ||||||||||
|
(kg) Weight |
205 | 350 | 490 | 600 | 860 | 890 | 1100 | 1950 | 2310 | ||
