Mooring Hawsers
- Category:Mooring Line
- Material:Nylon
- Standards:OCIMF Guidelines
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Mooring Hawsers:
Mooring Hawsers, according to ‘OCIMF Guidelines for the Purchasing and Testing of SPM Hawsers’, are available to suit any terminal operation. Single leg or grommet type with double braid construction, in nylon (100% polyamide) c/w end terminations, PU encapsulation and flotation to suit any arrangement. Load characteristics as detailed below.
Other sizes available on request
Size Table
| Dia.(mm) | Circ.(inch) | NDBS(MT Min.) | NDBS* (MT Min) | Weight (Kg/m) |
| 80 | 10 | 138 | 152 | 3.98 |
| 88 | 11 | 166 | 183 | 4.82 |
| 96 | 12 | 198 | 218 | 5.73 |
| 104 | 13 | 231 | 254 | 6.73 |
| 112 | 14 | 268 | 295 | 7.8 |
| 120 | 15 | 308 | 339 | 8.93 |
| 128 | 16 | 350 | 385 | 10.2 |
| 136 | 17 | 396 | 436 | 11.5 |
| 144 | 18 | 443 | 487 | 12.9 |
| 152 | 19 | 495 | 545 | 14.47 |
| 160 | 20 | 547 | 602 | 16.03 |
| 168 | 21 | 599 | 659 | 17.6 |
| 176 | 22 | 660 | 726 | 19.37 |
| 184 | 23 | 721 | 793 | 21.13 |
| 192 | 24 | 782 | 860 | 22.9 |
