| SIZE | M | A | B | C | D | E | H |
| M5 | KJ5 | 12.5 | 80 | 7.5 | 4.8 | 8.5 | 128 |
| M6 | 6 | 15 | 92 | 9 | 5.8 | 10 | 145 |
| M8 | 8 | 17 | 112 | 11 | 7.8 | 13.5 | 174 |
| M10 | 10 | 20 | 120 | 12 | 9.8 | 17 | 204 |
| M12 | 12 | 24 | 150 | 15 | 11.8 | 21 | 256 |
| M14 | 14 | 28 | 170 | 18 | 13.8 | 23 | 290 |
| M16 | 16 | 32.6 | 190 | 21 | 15.8 | 27 | 327 |
| M20 | 20 | 37 | 210 | 24 | 19.8 | 33 | 380 |
| M22 | 22 | 一 | 一 | 一 | 21.8 | 一 | 一 |
| M24 | 24 | 一 | 一 | 一 | 23.8 | 一 | 一 |
| M36 | 36 | 69 | 300 | 45 | 35 | 一 | 584 |
Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet
Turnbuckle
EU Closed Body Turnbuckle
SIZE M A B C D E H M5 KJ5 12.5 80 ...
ISO9001 Supplier
Class Certificate
Export Supply
Key Highlights
Category
Turnbuckle
Material
Stainless steel
Weight / Size
SIZE M A B C D E H M5 KJ5 12.5 80 7.5 4.8 8.5 128 M6 6 15 92 9 5.8 10 14...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.
Technical Specifications
Category
Turnbuckle
Model / SKU
EU-CLOSED-BODY-TURNBUCKLE
Material
Stainless steel
Weight / Size
SIZE M A B C D E H M5 KJ5 12.5 80 7.5 4.8 8.5 128 M6 6 15 92 9 5.8 10 145 M8 8 17 112 11 7.8 13.5 174 M10 10 20 120 12 9.8 17 204 M12 12 24 150 15 11.8 21 256 M14 14 28 170 18 13.8 23 290 M16 16 32.6 190 21 15.8 27 327 M20 20 37 210 24 19.8 33 380 M22 22 一 一 一 21.8 一 一 M24 24 一 一 一 23.8 一 一 M36 36 69 300 45 35 一 584
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
