| SIZE | A | B | C | D | L | L1 | WLL(T) |
| M4 | 30 | 58 | 5 | 6.5 | 80 | 131 | 0.025 |
| M5 | 34 | 70 | 6 | 8 | 96 | 146 | 0.04 |
| M6 | 44 | 90 | 8 | 10 | 122 | 190 | 0.1 |
| M8 | 58 | 120 | 12 | 14 | 164 | 255 | 0.2 |
| M10 | 73 | 150 | 13 | 16 | 205 | 325 | 0.3 |
| M12 | 97 | 200 | 15 | 18 | 264 | 425 | 0.5 |
| M14 | 110 | 225 | 18 | 20 | 300 | 486 | 0.7 |
| M16 | 122 | 250 | 20 | 26 | 337 | 548 | 0.8 |
| M20 | 147 | 300 | 25 | 30 | 406 | 646 | 1.2 |
Jinbo Marine
Marine & Offshore Equipment Datasheet
Product Datasheet
Turnbuckle
EU Type Turnbuckle
SIZE A B C D L L1 WLL(T) M4 30 58 5 ...
ISO9001 Supplier
Class Certificate
Export Supply
Key Highlights
Category
Turnbuckle
Material
Stainless steel
Weight / Size
SIZE A B C D L L1 WLL(T) M4 30 58 5 6.5 80 131 0.025 M5 34 70 6 8 96 146...
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
We can supply according to your requirement, drawings, class certificate needs, and delivery schedule.
Technical Specifications
Category
Turnbuckle
Model / SKU
EU-TYPE-TURNBUCKLE
Material
Stainless steel
Weight / Size
SIZE A B C D L L1 WLL(T) M4 30 58 5 6.5 80 131 0.025 M5 34 70 6 8 96 146 0.04 M6 44 90 8 10 122 190 0.1 M8 58 120 12 14 164 255 0.2 M10 73 150 13 16 205 325 0.3 M12 97 200 15 18 264 425 0.5 M14 110 225 18 20 300 486 0.7 M16 122 250 20 26 337 548 0.8 M20 147 300 25 30 406 646 1.2
Certificate
ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty
12 Months unless specified otherwise
Origin
China
