Single-Deck Stainless Steel Navigation Signal Light CXH-1S
- Category:Marine Navigation Signal Light
- Material:Stainless Steel
- Standards:IEC60598-1-2008
- Certificate:CCS Type Approval Certificate
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China Single-Deck Stainless Steel Navigation Signal Light CXH-1S:
The Navigation Signal Light used to the ship with length 50M or above as lamp signal liaison when night navigation.
Product Advantage:
1. Easy to Install and replace the bulb with a leakage hole at the bottom
2. The sheel is made of stainless steel, corrosion resistance and impact resistance
3. The shade is made of polycarbonate, UV Resistance and non-discolouring color.
Standards:
1. Confirm to the international regulation for preventing collision at sea, 1972 and grade entry norms for steel ships.
2. Confirm to the International Standard IEC60598-1-2008.
3. Confirm to the standard of marine electric signal light’s technical condition GB/T 3028-2012.
Main Specification:
| Voltage | 24V | 110V | 220V |
| Power | 30W | 60W | 65W |
| Lamp Holder | P28S | ||
| Protection Class | IP56 | ||
| Cable Diameter | Dia.11 | ||
| Name | Type | Visibility | Level Arc | Color | Weight |
| Starboard Light | CXH1-1S | 3n.m | 112.5o | Green | 2.2KGS |
| Port Light | CXH2-1S | 3n.m | 112.5o | Red | 2.2KGS |
| Masthead Light | CXH3-1S | 6n.m | 225o | White | 2.`KGS |
| Stern Light | CXH4-1S | 3n.m | 135o | White/Yellow | 2.3KGS |
| All-round- Light | CXH6-1S | 3n.m | 360o | Red/green/white | 2.0KGS |
