Marine Equipment
WCB Series Gear Pump Marine
WCB-type gear oil pump belongs to a low pressure micro-portable energy-efficient pump, suitable for flats for sale without motive power switch to oil barrels, also applies to oil refinerie...
Loading product images...
WCB Series Gear Pump Marine
PDF Datasheet
We can supply according to your requirement.
China WCB Series Gear Pump Marine:
WCB-type gear oil pump belongs to a low pressure micro-portable energy-efficient pump, suitable for flats for sale without motive power switch to oil barrels, also applies to oil refineries, power plants, power plants, transformer substation (room) and the oil depot .
Main Specification
| Type | Capacity | Pressure | Oil Height | Head | Voltage | Speed | Power | Access caliber | Weight | Size | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (l/min) | (MPa) | (m) | (m) | (V) | (r/min) | (kW) | (mm) | (kg) | L | B | H | |
| WCB-30 | 30 | 0.3 | 5 | 30 | 220 | 2800 | 0.37 | 20 | 14.5 | 390 | 196 | 220 |
| WCB-50 | 50 | 0.3 | 5 | 30 | 220 | 2800 | 0.55 | 25 | 14.5 | 400 | 210 | 220 |
| WCB-75 | 75 | 0.3 | 4 | 30 | 220 | 2800 | 0.75 | 25 | 15 | 420 | 230 | 230 |
| WCB1-75 | 75 | 0.3 | 4 | 30 | 380 | 2800 | 0.75 | 25 | 15 | 420 | 230 | 230 |
Note: 380V technical parameters remain unchanged
Type:
WCB: Gear Pump
75: Capacity 75L/min
