HSH-A619 Lever Hoist

Request a Quote Not what you need, please send your RFQs via Email.

Details

Two points support,the driving shaft is fixed by cantilever structure,the hand wheel is stamping,more compact and reliable operation.

The friction disc and ratchet as replacement parts, more convenient.

It on Ratchet part,the performance of maintenance-free bearing is close to rolling bearing,better corrosion resistance.

The material of hook is alloy steel,passed heat treatment,it iincludes stamping safety latch.

Optional feature:cast safety latch.

The material of handle seeve is oil resistant rubber. Grade 80 load chain.

Optional feature:Grade 100 load chain.

Grade 80 loade chain is accorded with EN818-7 standard.

The stamping enlarged end ring support 2.5 times of rated load.

Optional feature: cast enlarged end ring and mobile end ring.

Brake seat and driving shaft connected by screw thread.

Model		H0075-A619	H015-A619	H030-A619	H060-A619	H090-A619
Capacity	Tons	0.75	1.5	3	6	9
Load Chain	mm	6x18	8x24	10x30	10x30	10x30
Strands of load chain		1	1	1	2	3
Strands of lift	mm	1.5	1.5	1.5	1.5	1.5
Load chain distance by rotating the hand wheel one circle	mm	19.8	21.3	16.8	8.4	5.6
Effort required to lift rated load	N	140	240	320	340	360
Running test load	KN	9.2	18.4	36.8	73.5	110.3
Dimensions(mm)	A	148	176	195	195	195
	B	88	102	109	109	109
	C	135	162	211	254	319
	D	37	45	50	64	85
	Hmin	320	380	480	620	700
	L	290	420	420	420	420
	K	26	32.5	37	46	50
Extra weight per meters of extra lift		0.8	1.4	2.2	4.3	6.6
Net weight		0.3	11	18.7	30	41.2
