ZPT300-26 Axial Flow Propulsion Pump
- Category:Water Jet Propulsion
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China ZPT300-26 Axial Flow Propulsion Pump:
ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other boats for propulsion device to use. The pump can choose motor drive,hydraulic pressure drive or diesel engine drives and other three ways.
| Main Technical Data | ||||
| Model |
Flow rate Q（m³/h） |
Lift H (m) |
Rev speed r/min |
Outlet diameter (mm) |
| ZPT200-26 | 320 | 26 | 1460 | 138 |
| ZPT250-26 | 500 | 26 | 1460 | 188 |
| ZPT300-26 | 720 | 26 | 1460 | 220 |
| ZPT350-24 | 1000 | 24 | 1460 | 250 |
| ZPT400-24 | 1380 | 24 | 980 | 268 |
| ZPT450-24 | 1600 | 24 | 980 | 300 |
| ZPT500-26 | 2200 | 26 | 980 | 360 |
| ZPT600-26 | 2600 | 26 | 730 | 460 |
| ZPT700-28 | 4860 | 28 | 730 | 520 |
| ZPT800-28 | 6200 | 28 | 585 | 600 |
| ZPT900-30 | 7600 | 30 | 585 | 720 |
| ZPT1000-28 | 12000 | 28 | 585 | 800 |
