10Ton to 90Ton TB-Series SWL Trawl Blocks
- Category:JIS Steel Cargo Block
- Packing Details:Wooden Box
- Delivery Time:20 days
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China 10Ton to 90Ton TB-Series SWL Trawl Blocks:
Work hardening manganese steel sheaves maximize wire rope and sheave life
Equipped with tapered roller bearings for long life in higher line speed applications.
Swivel eyes designed with thrust bearings for ease of rotation.
Galvanized for a durable and corrosion resistant finish.
| HEIGHT | THICKNESS | WIDTH | THROAT WIDTH | THROAT HEIGHT | EYE INSIDE HEIGHT | EYE INSIDE WIDTH |
| A | B | C | E | F | G | H |
| 25 | 8.75 | 11 | 5.38 | 5 | 3.75 | 2.5 |
| 39 | 12 | 17 | 7.38 | 9 | 4.5 | 3 |
| 43 | 12 | 25 | 7.38 | 7.38 | 4.5 | 3 |
| 55 | 16 | 31 | 7.38 | 6 | 3.38 | 3.38 |
