G-400 Eye Nuts, SS304 OR SS316
STD.TAP SIZE (in.) WORKING LOAD LIMIT (t)* WEIGHT each(kg) DIMENSIONS (in.) A C D ...
Loading product images...
G-400 Eye Nuts, SS304 OR SS316
PDF Datasheet
We can supply according to your requirement.
China G-400 Eye Nuts, SS304 OR SS316:
| STD.TAP SIZE (in.) | WORKING LOAD LIMIT (t)* | WEIGHT each(kg) | DIMENSIONS (in.) | |||||||||
| A | C | D | E | F | J | K | N | T | W | |||
| 1/4 | 0.24 | 0.04 | 31.8 | 19.1 | 25.4 | 19.1 | 12.7 | 17.5 | 16 | 11.7 | 43.7 | 7.85 |
| 3/8 | 0.57 | 0.08 | 41.1 | 25.4 | 30.5 | 21.1 | 14.2 | 20.6 | 22.6 | 14.7 | 53 | 10.4 |
| 1/2 | 1.02 | 0.13 | 51 | 31.8 | 36.6 | 27.4 | 20.6 | 25.4 | 27.7 | 18.5 | 63.5 | 12.7 |
| 5/8 | 1.63 | 0.27 | 63.5 | 38.1 | 48.8 | 34.3 | 25.4 | 33.3 | 33.3 | 21.1 | 82.5 | 17.5 |
| 3/4 | 2.36 | 0.45 | 76 | 44.5 | 58 | 40.4 | 28.4 | 38.1 | 39.9 | 26.7 | 100 | 21.3 |
| 7/8 | 3.27 | 0.75 | 89 | 51 | 63.5 | 49.8 | 35.1 | 47.8 | 45 | 29 | 111 | 25.4 |
| 1 | 4.54 | 1.22 | 102 | 57 | 74 | 56 | 39.6 | 54 | 51.5 | 33 | 129 | 30.2 |
| 1-1/4 | 7.03 | 1.98 | 114 | 63.5 | 85 | 62.5 | 47.8 | 60.5 | 57.5 | 38.6 | 149 | 35.1 |
| 1-3/8 | 8.39 | 2.27 | 127 | 70 | 102 | 68.5 | 51 | 65 | 64.5 | 42.4 | 165 | 38.1 |
| 1-1/2 | 10.21 | 3.08 | 143 | 79 | 109 | 78.5 | 57 | 76 | 71.5 | 46.5 | 179 | 42.2 |
| 2 | 18.14 | 6.62 | 181 | 104 | 152 | 104 | 79.5 | 95.5 | 93.5 | 63 | 257 | 49.3 |
