DHP Series Electric Chain Hoist
The synchronous electric hoist is an intelligent lifting device designed for heavy-duty syn-chronized lifting operations. It enables precisecoordination through multi-unit linkage and a central control system, ideal for large steels tructure hoisting, bridge construction, stage machinery lifting, and other scenarios requiring stability and synchronization under heavy loads.
| Model | DHP5 | DHP7.5 | DHP10 | DHP15 | DHP20 | DHP30 | |
| Standard Lifting Weight (t) | 5 | 7.5 | 10 | 15 | 20 | 30 | |
| Lifting Speed(m/min) | 0.18 | 0.12 | 0.09/0.26 | 0.06 | 0.09 | 0.06 | |
| Hmin Headroom(hook to hook)Hmin(mm) | 600 | 700 | 850 | 980 | 1200 | 1500 | |
| No.of load chaintall lines(n) | 2 | 3 | 4 | 6 | 6 | 12 | |
| Diameter of load chain (mm) | 10 | 10 | 10 | 10 | 10 | 10 | |
| Lifting Height (m) | 3-9m | 3-9m | 3-9m | 3-9m | 3-9m | 3-9m | |
| Motor Power(w) | 500 | 500 | 500/750 | 500 | 500x2 | 500x2 | |
| Power supplyvoltage | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | 380V/50Hz | |
| Net weight (3m) kg | 50 | 67 | 85 | 120 | 180 | 245 | |
| Gross Weight(3m)kg | 61 | 78 | 95 | 135 | 200 | 270 | |
