LMZ-6 Voltage Transformer

LMZ-6 Voltage Transformer 1. The product complies with the standards GB1208 and IEC185 2. Rated insulation level 12/42/75KV, 7.2/25/60KV 3. Rated frequency 50Hz, 60Hz 4. Rated secon...

Marine Transformers1 Photos ISO9001 Supplier

Loading product images...

LMZ-6 Voltage Transformer

Category: Marine Transformers

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote PDF Datasheet

We can supply according to your requirement.

LMZ-6 Voltage Transformer

1. The product complies with the standards GB1208 and IEC185
2. Rated insulation level 12/42/75KV, 7.2/25/60KV
3. Rated frequency 50Hz, 60Hz
4. Rated secondary current 5A, 1A

LMZ-6 Voltage Transformer Parameters

Model	Rated Primary Current A	Accuracy Combination	Rated Output/VA
LMZ-10	50，75，100，150，200	3/3	5/5
LMZ-10	300,400,600	0.5/10P10	10/15
LMZ-6	50，75，100，150，200	3/3	5/5
	50，75，100，150，200	0.5/10P10	10/15
	300,400,600	0.5/0.5	10/10
	300,400,600	0.5/10P10	10/15
