MFC25-300A Mixed Type Pair of Arms Modules

MFC25-300A Mixed Type Pair of Arms Modules       IT(AV) ITSM I2t VFM VRRM IRRM VGT IGT IH di/dt dv/dt VISO TJ TC Fig.No Tpye A A 103A2s V V ...

Sensor1 Photos ISO9001 Supplier

Loading product images...

Category: Sensor

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

We can supply according to your requirement.

China MFC25-300A Mixed Type Pair of Arms Modules:

MFC25-300A Mixed Type Pair of Arms Modules

IT(AV)	ITSM	I2t	VFM	VRRM	IRRM	VGT	IGT	IH	di/dt	dv/dt	VISO	TJ	TC	Fig.No
Tpye	A	A	103A2s	V	V	mA	V	mA	mA	A/μ s	V/μ s	V	℃	℃
MFC25	25	450	1.3	≤1.8	1000~1600	≤2	≤3	20~100	10~100	100	500	2500	-40~+125	80	19
MFC55	55	990	5.1	≤1.8	1000~1600	≤2	≤3	20~100	10~100	100	500	2500	-40~+125	80	19
MFC70	70	1050	8.6	≤1.8	1000~1600	≤2	≤3	20~100	10~100	100	500	2500	-40~+125	80	21
MFC90	90	1350	14.7	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	21
MFC110	110	1650	22.5	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	21、22
MFC135	135	2025	31.9	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	22
MFC150	150	2250	42.9	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	22
MFC200	200	3000	78.5	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	24
MFC300	300	4500	133	≤2	1000~1600	≤2	≤4	20~100	10~100	150	500	2500	-40~+125	80	24
