Medium Pressure Air Cooled Marine Diesel Engine Air Compressor

Many types of air compressors can be driven by diesel engines, which can serve as emergency compressors. 1.This greatly facilitates the absence of power supply occasions. 2.Diesel engin...

Medium Pressure Air Cooled Marine Air Compressor1 Photos ISO9001 Supplier

Loading product images...

Medium Pressure Air Cooled Marine Diesel Engine Air Compressor

Category: Medium Pressure Air Cooled Marine Air Compressor

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote PDF Datasheet

We can supply according to your requirement.

China Medium Pressure Air Cooled Marine Diesel Engine Air Compressor:

Many types of air compressors can be driven by diesel engines, which can serve as emergency compressors.
1.This greatly facilitates the absence of power supply occasions.

2.Diesel engines require regular refueling of diesel as a combustion power.

Medium Pressure Air Cooled Marine Diesel Engine Air Compressor

Specification

Model	Type	Displacement capacity	Rated pressure	Rotate speed	Model of diesel engine	Overall size
Model	Type	m3/h	Mpa	r/min	Model of diesel engine	mm
CZ-20/30	Air cooling	20	3.0	1000	ZS1100 or R175 or 186 hand operated start	1310x650x800
CZ-10/30		10		500		1310x650x800
CZF20.4/3-C		20.4		600		1360x650x820
CWF-40/30		40		500		1400x650x850
