R03 Protection EYE Type Round Flexible Sling

Description: When choosing the specifications of hoisting belt, it is necessary to take into account the size, weight, shape of the load to be hoisted, as well as the method of ...

Chain Sling2 Photos ISO9001 Supplier

R03 Protection EYE Type Round Flexible Sling

Category: Chain Sling
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
Warranty: 12 Months unless specified otherwise
Place of Origin: China

We can supply according to your requirement.

Description:


When choosing the specifications of hoisting belt, it is necessary to take into account the size, weight, shape of the load to be hoisted, as well as the method of hoisting to be used, and other common factors of the use of mode coefficients, given the limit of working force requirements, while working environment, load types must be taken into account. It is necessary to select a sling with adequate capacity and suitable length to meet the operation mode. If multiple sling belts are used simultaneously for lifting load, the same type of sling belts must be selected; the raw materials of flat sling belts can not be affected by environment or load. Whether or not accessories or soft lugs are required, careful consideration must be given to matching the end of the hoisting belt with the auxiliary accessories and lifting equipment.

Advantage:


1, light weight and easy to use.
2, do not damage the surface of suspended objects;
3. Lifting is stable and safe.
4, high strength, can judge tonnage according to color.
5, improve labor efficiency and save costs.
6, corrosion resistance, good wear resistance;
7. It is widely used in port, wharf, chemical industry, steel, machinery, installation and other lifting places.

Art.No. Working Load Limit(kg) Approx Thickness(mm) Approx Width(mm) Minimum length L(m)
R03-01 1000 11 50 1
R03-02 2000 12 60 1.5
R03-03 3000 14 70 1.5
R03-04 4000 15 80 1.5
R03-05 5000 23 90 1.5
R03-06 6000 25 90 2
R03-08 8000 26 100 3
R03-10 10000 27 110 3
R03-12 12000 28 125 3
R03-15 15000 29 150 3
R03-20 20000 31 180 3
R03-25 25000 34 200 3
R03-30 30000 36 220 4
R03-40 40000 40 250 4
R03-50 50000 46 300 4

DNV CLASS TEST:
