XOC-01 15ppm Bilge Water Alarm
Description: Marine XOC-01 15ppm bilge water alarm instrument is not only used for the continuous detection of oil and sewage in the bilge of ship, but also used for the moni...
XOC-01 15ppm Bilge Water Alarm
PDF Datasheet
We can supply according to your requirement.
Description:
Marine XOC-01 15ppm bilge water alarm instrument is not only used for the continuous detection of oil and sewage in the bilge of ship, but also used for the monitoring of oily waste water in the fields of chemical industry, petroleum and environment protection etc.
Model XOC-01 15ppm bilge water alarm has acquired the approval of CCS, and its technical performance conforms to the third part equipments, the second section Authiorized Test and Performance Technical Conditions of 15PPM Warning Device for Bilge Water, MEPC.107(49) Resolution.
Technical Data:
| Measurement Range | 0～30ppm |
| Measurement Precision | ±5ppm |
| Alarm indication | two emitting LED |
| Concentration Value Display | 3-bit LED |
| Alarm Point | 15ppm |
| Alarm 1 Time-delay | 2S |
| Alarm 2 Time-delay | 6S |
| Load of contact of alarm replay | 5A/220V |
| Output analog signal | 4～20mA or 0～10V DC |
| Operational Life | More Than 60000h |
| Feed Liquid Flow Amount | 0.5～3.5L/min |
| Feed Liquid Pressure | 0.01～0.5Mpa |
| Weight | 13.5Kg |
| Power Supply | AC220±10% 50Hz±5% |
| Safeguard Grade | IP45 |
| Operational Environment | 0～55℃ |
