ZPT300-26 Axial Flow Propulsion Pump
ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other b...
ZPT300-26 Axial Flow Propulsion Pump
We can supply according to your requirement.
China ZPT300-26 Axial Flow Propulsion Pump:
ZPT type axial flow water pump jet is suitable for taxi boat, lateral wall type such as the hovercraft high performance speedboat background push device,modified also used for other boats for propulsion device to use. The pump can choose motor drive,hydraulic pressure drive or diesel engine drives and other three ways.
| Main Technical Data | ||||
| Model | Flow rate Q(m³/h) | Lift H (m) | Rev speed r/min | Outlet diameter (mm) |
| ZPT200-26 | 320 | 26 | 1460 | 138 |
| ZPT250-26 | 500 | 26 | 1460 | 188 |
| ZPT300-26 | 720 | 26 | 1460 | 220 |
| ZPT350-24 | 1000 | 24 | 1460 | 250 |
| ZPT400-24 | 1380 | 24 | 980 | 268 |
| ZPT450-24 | 1600 | 24 | 980 | 300 |
| ZPT500-26 | 2200 | 26 | 980 | 360 |
| ZPT600-26 | 2600 | 26 | 730 | 460 |
| ZPT700-28 | 4860 | 28 | 730 | 520 |
| ZPT800-28 | 6200 | 28 | 585 | 600 |
| ZPT900-30 | 7600 | 30 | 585 | 720 |
| ZPT1000-28 | 12000 | 28 | 585 | 800 |
