DRG Series Electric Heating Hot Water Tank

  • Category:Hot Water Tank
  • Certificate:CCS,EC,GL and BV certificate.
  • Material:Carbon Steel
  • Packing Details:Standard Export Packaging
  • Delivery Time:15-20days
  • Supply Ability:10 sets/month
  • Fob Price:Get Latest Price Now
  • Place of Origin:China
Request a Quote Not what you need, please send your RFQs via Email.

Details

China DRG Series Electric Heating Hot Water Tank:

This series tank is suitable for heating water on the ship or platform, heated fresh water for crew use.

This series hot water tank can be combined to use with fresh water pressure tank on board , namely use fresh water to renew the stock of hot water tank, and then heated by electric for useage of entire vessel.

Material:Normal steel,stainless steel 304,stainless steel 316.

Specification:

Model DRG-0.12 DRG-0.2 DRG-0.3 DRG-0.5 DRG-1
Capacity(m3) 0.12 0.2 0.3 0.5 1
Working Pressure (MPa) 0.4
Design Pressure (MPa) 0.44
Testing Pressure (MPa) 0.66
Safety Valve Open Pressure (MPa) 0.42
Water Inlet Temp. (°C) 15
Water Outlet Temp. (°C) 65
Hot-water capacity (kg/h) 180 360 540 720 900
Electric Heating Power (kw) 12 24 36 48 60
The laying of outer surface of insulation layer thickness (mm) 40
Outsourcing galvanized steel sheet thickness (mm) 0.7
