Electric-Controlled Foam Water Dual Monitor
Electric-Controlled Foam Water Dual Monitor Item No. Model No. PLKDC300/1200 PLKDC300/900 PLKD...
Loading product images...
Electric-Controlled Foam Water Dual Monitor
PDF Datasheet
We can supply according to your requirement.
China Electric-Controlled Foam Water Dual Monitor:
Electric-Controlled Foam Water Dual Monitor
| Item No. | Model No. | PLKDC300/1200 | PLKDC300/900 | PLKDC300/720 | |
| 1 | Nominal working pressure | 1.2mpa | |||
| 2 | Working pressure range | 0.4-1.6Mpa | |||
| 3 | Flow rate | Water | 1200m3/h | 900m3/h | 720m3/h |
| Foam | 300m3/h | ||||
| 4 | Spray range | Water | ≥120m | ≥110m | ≥100m |
| Foam | ≥70m | ||||
| 5 | Horizontal rotate angle | 300° | |||
| 6 | Vertical angle | -30°~+70° | |||
| 7 | Expansion rate | ≥6 | |||
| 8 | 25% Drainage time | ≥2.5min | |||
| 9 | Power | AC380V 50HZ DC24V | |||
| 10 | Motor power | Horizontal rotate:1.1kw,Vertical rotate:2.2kw | |||
| 11 | Remote control distance | ≤150m | |||
| 12 | Connec way | Flange connect,DN200 1.6Mpa HG/T20592-2009 | |||
