Electric Fire Monitor 5L/S

Request a Quote Not what you need, please send your RFQs via Email.

Details

China Electric Fire Monitor 5L/S:

Electric Fire Monitor 5L/S

Flow Range: 5L/S (80GPM)
Working Pressure: 6 bar~ 8 bar
Max Reach @ Max Flow: 40M
Max. Range of motion: +/-90°Vert , 350°Rot
Max fog angle :120°
Turning speed:18 degrees/sec
Material (body):304L Stainless Steel, 316L Stainless Steel is also available
Material (Gear):Bronze
Material (nozzle):Aluminum
power supply:12/24VDC or 100-230VAC
Power Consumption normal/Max:50W/150W
Weight incl. nozzle:appox 17kg
Cable Length Monitor- CPU:5m
Cable Length Joystick-CPU:5m standard/ other length available
Pump requirement for minimum performance:5L/S@ 6 bar
Pipe dimensions for installation: 2 Inch
Monitor Inlet:2” male BSP or DN65 flange
Monitor Outlet:2 inch (50mm)
Water way size: 2 inch
PACKAGE: SS MONITOR, NOZZLE, CONTROL BOX, JOYSTICK, CABLES, WIRELESS CONTROL (OPTIONAL)
