Sch 20 ASTM A234 WPB 90D ELBOW
- Category:Elbow
- Material:Carbon steel
- Standards:ASTM A234 WPB
- Fob Price:Get Latest Price Now
- Place of Origin:China
Details
Product Description:
Carbon Steel 90D ELBOW(SR),ASTM A234 WPB,SMLS,SCH.20
Sch is short for schedule,said wall thickness and pipe fittings size is specified with two non-dimensional numbers:a nominal
pipe fittings size for diameter based on inches,and a schedule (Sched. or Sch.) for wall thickness.
Wall thickness level:Sch10,Sch20,Sch30,Sch40,Sch60,Sch80,Sch100,Sch120,Sch140,Sch160 etc
A234 Piping Fittings of Wrought Carbon Steel and Alloy Steel for Moderate and high Temperature Service
ASME\ANSI B16.9:Factory-Made Wrought Steel Butt welding Fittings
ASME B16.28:Wrought Steel Butt welding Short Radius Elbows and Returns
Specification:
|
Short Radius Elbow 90deg |
SCH20 |
|||
|
OD |
ND |
INCH |
Weight |
usd |
|
219.1 |
200 |
8 |
10.6 |
12-200 |
|
273 |
250 |
10 |
16.4 |
12-200 |
|
323.8 |
300 |
12 |
24.1 |
12-200 |
|
355.6 |
350 |
14 |
38.8 |
12-200 |
|
406.4 |
400 |
16 |
50.5 |
12-200 |
|
457.2 |
450 |
18 |
64.4 |
12-200 |
|
508 |
500 |
20 |
95.1 |
12-200 |
|
558.8 |
550 |
22 |
115.0 |
12-200 |
|
609.6 |
600 |
24 |
137.0 |
12-200 |
NB (nominal bore) is the European
designation equivalent to NPS is DN (diamètre nominal/nominal
diameter/Durchmesser nach Norm), in which sizes are measured in millimeters.
NB (nominal bore) is also frequently used interchangeably with NPS.
OD is the outside diameter of the pipe and is fixed for a given size.
