UHZ-57-B Magnetic Turnover Plate Level Gauge

UHZ-57-B Side mounting type magnetic turnover plate level gauge is a fresh type, like direct reading level gauge, its main material is stainless steel,it can replace glass tube/plate type level gauge completely. It adopt magnetic coupling theory,let the liquid medium isolated from indicator, it is more safe and reliable to do inspection of inflammable medium, explosive medium and toxic medium.

Clear indication,convenient to read. It can satisfy inspection from remote area if equip with other instruments.

Indication type: Red and white turnover column or turnover float, float tracking type.

Measure precision:±1cm,±2cm(turnover column) . ±1cm(float type)

Measure range:0~400mm to 0~20000mm

Medium density:≥0.45g/cm³

Medium viscosity:≤0.02Pa.s (under medium working environment)

Working temperature:≤0.02Pa.s

Working Pressure:-100KPa-4.0MPa
