US Eye Bolt G-277
- Category:Eye Bolts & Nuts
- Material:Stainless steel
- Fob Price:Get Latest Price Now
- Place of Origin:China
Request a Quote
Not what you need, please send your RFQs via Email.
Details
China US Eye Bolt G-277:
| SIZE |
A inch |
B inch |
C inch |
D inch |
E inch |
F inch |
G inch |
H inch |
J inch |
WLL lbs |
| 1/4x2 | 0.25 | 0.5 | 0.88 | 0.19 | 1.5 | 2 | 2.94 | 0.5 | 0.47 | 500 |
| 1/4x4 | 0.25 | 0.5 | 0.88 | 0.19 | 2.5 | 4 | 4.94 | 0.5 | 0.47 | 500 |
| 5/16 x 21/4 | 0.31 | 0.62 | 1.12 | 0.25 | 1.5 | 2.25 | 3.5 | 0.69 | 0.56 | 800 |
| 5/16 x 41/4 | 0.31 | 0.62 | 1.12 | 0.25 | 2.5 | 4.25 | 5.5 | 0.69 | 0.56 | 800 |
| 3/8 x 21/2 | 0.38 | 0.75 | 1.38 | 0.31 | 1.5 | 2.5 | 3.97 | 0.78 | 0.66 | 1200 |
| 3/8 x 41/2 | 0.38 | 0.75 | 1.38 | 0.31 | 2.5 | 4.5 | 5.97 | 0.78 | 0.66 | 1200 |
| 1/2 x 3/4 | 0.5 | 1 | 1.75 | 0.38 | 1.5 | 3.25 | 5.12 | 1 | 0.91 | 2200 |
| 1/2x6 | 0.5 | 1 | 1.75 | 0.38 | 3 | 6 | 7.88 | 1 | 0.91 | 2200 |
| 5/8x4 | 0.62 | 1.25 | 2.25 | 0.5 | 2 | 4 | 6.44 | 1.31 | 1.12 | 3500 |
| 5/8x6 | 0.62 | 1.25 | 2.25 | 0.5 | 3 | 6 | 8.44 | 1.31 | 1.12 | 3500 |
| 3/4 x 41/2 | 0.75 | 1.5 | 2.75 | 0.62 | 2 | 4.5 | 7.44 | 1.56 | 1.38 | 5200 |
| 3/4x6 | 0.75 | 1.5 | 2.75 | 0.62 | 3 | 6 | 8.94 | 1.56 | 1.38 | 5200 |
| 3/4x5 | 0.88 | 1.75 | 3.25 | 0.75 | 2.5 | 5 | 8.47 | 1.84 | 1.56 | 7200 |
| 1x6 | 1 | 2 | 3.75 | 0.88 | 3 | 6 | 9.97 | 2.09 | 1.81 | 10000 |
| 1x9 | 1 | 2 | 3.75 | 0.88 | 4 | 9 | 12.97 | 2.09 | 1.81 | 10000 |
| 11/4 x 8 | 1.25 | 2.25 | 4.5 | 1 | 4 | 8 | 12.97 | 2.47 | 2.28 | 15200 |
| 11/4X 12 | 1.25 | 2.25 | 4.5 | 1 | 4 | 12 | 16.72 | 2.47 | 2.28 | 15200 |
| ifex 15 | 1.25 | 3 | 5.5 | 1.25 | 6 | 15 | 20.75 | 3 | 2.75 | 21400 |
