Gasoline welding generator
Gasoline welding generator Parameter Gasoline welding generator Generator Model 190 ...
Loading product images...
Gasoline welding generator
PDF Datasheet
We can supply according to your requirement.
Gasoline welding generator
Parameter
| Gasoline welding generator | |||||
| Generator | Model | 190 | 200G | 250GE | 300GE |
| Rated output power(KW) | 3.64 | 5 | 4 | 4 | |
| Rated output current(A) | 140 | 140 | 250 | 300 | |
| Current adjustment(A) | 50-200 | 50-200 | 80-250 | 80-300 | |
| Rated voltage(V) | 26 | 26 | 32 | 32 | |
| Load rate | 50% | 50% | 100% | 100% | |
| Welding rod | ∮2.0-4.0mm | ∮2.0-4.0mm | ∮3.2-5.0mm | ∮3.2-5.0mm | |
| Rated power(KW) | 4.5 | 5 | 7.5 | 9.6 | |
| Max.power(KW) | 5 | 5.5 | 8 | 10 | |
| Rated frequency(Hz) | 50 | 50 | 50 | 50 | |
| 1-Phase AC voltage | 220 | 220(380) | 220 | 220 | |
| DC output | 12V/8.3A | 12V/8.3A | 12V/8.3A | 12V/8.3A | |
| Power factor(cos∮) | 1 | 1 | 1 | 1 | |
| Rated rotation speed(rpm) | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 | |
| Noise level | 72 | 72 | 72 | 72 | |
| Fuel tank capacity(L) | 25 | 25 | 30 | 30 | |
| Structure type | Open Frame type | ||||
| Engine | Engine Model | 188F | 190F | 620FE | 670FE |
| Type | Single cylinder engine | Two cylinder engine | |||
| Displacement(ml) | 389 | 407 | 620 | 670 | |
| Max.output power(hp)/Speed(Rpm) | 13/3600 | 15/3600 | 22/3600 | 25/3600 | |
| Oil capacity(L) | 1.1 | 1.1 | 1.4 | 1.9 | |
| starting method | Recoil start | Electric start | |||
| Options | Electric start system | Available | Available | Available | Available |
| 3-Phase Ac voltage | Available | Available | Available | Available | |
| 4-wheel vehicle set | Available | Available | Available | Available | |
| 2-Wheel and handle | Available | Available | Available | Available | |
| Side panel | Available | Available | Available | Available | |
| Remote control system | Available | Available | Available | Available | |
| ATS | Available | Available | Available | Available | |
| Pack | Packing size(mm) | 700x550x570 | 750x620x610 | 975x665x760 | 975x665x760 |
| Net weight(Kgs) | 88 | 90 | 160 | 160 | |
| Gross weight(Kgs) | 92 | 99 | 168 | 168 | |
| 20FT Qty | 273 | 216 | 120 | 120 | |
