Marine Equipment
XF Mooring Buoy
We supply the various kinds of mooring buoy for many toonage ships to be mounted. Easy operation and maintenance, mooring buoy is the important equipment in harbors. ...
Loading product images...
PDF Datasheet
China XF Mooring Buoy:
We supply the various kinds of mooring buoy for many toonage ships to be mounted. Easy operation and maintenance, mooring buoy is the important equipment in harbors.
| Type | Buoyancy(t) | Diameterx Height(m) | Chain diameter(mm) | Lifting Eye(mm) | Sinker(t) | Mooring Shackle(mm) | Suitable for ship tonnage(t) |
| XF2.0-D1 | 3 | Φ2X1.74 | Φ62 | Φ45 | 4 | Φ90 | <2000 |
| XF2.6-D1 | 6 | Φ2.6X2.27 | Φ72 | Φ45 | 6 | Φ90 | <5000 |
| XF3.6-D1 | 19 | Φ3.6X2.14 | Φ90-Φ100 | Φ50 | 8 | Φ140 | <10000 |
| XF5.0-D1 | 28.5 | Φ5X3.4 | Φ122 | Φ60 | 12 | Φ140 | <12000 |
| XF5.5-D1 | 31.2 | Φ5.5X3 | Φ122 | Φ70 | <100000 | ||
| XF6.0-D1 | 34.2 | Φ6X3.2 | Φ122 | Φ80 | <150000 | ||
| XF8.0-D1 | 40.3 | Φ8X2.46 | Φ122 | Φ100 | 120 | Φ170 | <250000 |
