Doppler Speedlog

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

Dopper Speed Log

Specification

  • Display LCD: 7 Inch TFT 480x234 pixels
  • STW Speed: Arrow + Digital Speed Display
  • Data output: IEC 61162 - 1 VBW, VLW
  • Trip Counter: Measurement from 0 to 9999.99nm
  • Total Counter: measurement from 0 to 999999.99nm
  • Distance Accuracy: 0.2nm or 2%, whichever is greater
  • Speed Accuracy: 0.2kn or 2%, whichever is greater
  • Speed Range: -10 to +40kn
  • Powre supply: AC110/220v 50/60hz
  • Operating temp: -115 to +55degree C
  • Humidity: when 40+/-3 degree C,93%+/-2% relative
  • Compass safe distance: Displayer STD 1.08m Steer:0.45m controller STD 1.32m, Steer: 0.84m
  • Protection: Displayer IP23, Controller:IP23, Transceiver: IP56
