GPS Navigator

The KP-32 is an advanced GPS navigator with a SBAS receiver designed for coastal ships, fishing boats and pleasure craft. The powerful processor performs high-speed processing of position fixing and augmentation using SBAS correction. It comes with an easy to use track plotter which stores up to 2,500 track points. This compact and cost-effective unit offers extremely accurate position fixed. It is accurate to 15 meters and with SBAS mode activated, it’s accurate to within 3 meter.

• Improved accuracy with built-in SBAS receiver
• 4.5” silver bright LCD display
• Multiple display modes to suit a variety of navigational requirements
• Up to 999 waypoints, 50 routes and 2500 track points
• One-touch waypoint entry
• Customizable NavData screens
• Track back feature stores waypoints at user defined intervals for early trace-back cruise
• Way point & Route upload/download through RS-232C port

• Receiver type: GPS: Twelve discrete channels, C/A code, all-in-view. SBAS receiver
• Receiver frequency: L1 (1575.2 Mhz)
• Time to first fix: 15 second average(HOT start)
• Tracking velocity: 999 knots
• Geodetic system: WGS-84
• Accuracy: GPS-15m(95%), SBAS-3m(95%)
• Display: 4.5” diagonal 95(W)X63(H) mm LCD, 240x160 pixels
• Display Modes: plotter, highway, steering, speedometer, Nav data and 2 pages customizable display.
• Memory Capacity: 2500 ship’s track points, 999 waypoint with comments, 50 routes, 30waypoints
• Alarms: Arrival, Anchor watch, XTE, Speed, Time, Trip, Odometer
• Interface: output(NMEA0183 ver 2.0)
• Environment: Display unit(-15c to +55c), Antenna unit(-25c to +70c)
• Waterproofing: Display unit(IPX5), Antenna unit(IPX6).
