Eye Terminal Forged, SS304 OR SS316

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

China Eye Terminal Forged, SS304 OR SS316:

SIZE Φ1 Φ2 A B C D SWL
kgs 		BL
kgs
2.7 5.53 2.7 5.5 56 35 3 213 850
3.3 6.35 3.3 6.5 63 38 4 250 1000
4.3 7.5 4.3 8.5 77 45 5 338 1350
5.3 9.1 5.3 10.5 87 52 6 625 2500
6.4 12.5 6.4 13 107 63 7 1125 4500
8.4 16 8.4 14.5 133 80 10 1675 6700
10.5 18 10.5 16.3 159.5 100 11 1950 7800
12.5 21.5 12.5 19.3 180 120 15 2250 9000
14.8 25 14.8 23 235.5 140 20 3000 12000
