WTZ-280 Stainless Steel Anti-Vibration Type Thermometer

Request a Quote Not what you need, please send your RFQs via Email.
Download this page

Details

Product Description:

It is an electrical switch that can make electric circuit close or open according to the change of controlled medium temperature. It can be used In ship,freeze equipment or other industrial equipment,carry two position controlling to the temperature of gas,liquid or steam.

Main Technical Specification:

Model Measurement
range(℃) 		Accuracy Adjsutment range of insert length of temperature bulb（mm) Temperature bulb diameter Connection thread Casing material
WTZ-280 -40~60
-60~80
0~50
0~100 		0~150
20~120
60~160 		1.5 150-2000 15mm M27x2
G1/2"
G3/4“ 		Phenolic resin
Copper alloy
Stainless steel
WTQ-280 -60~40
-40~60 		0~200
0~250
0~300
0~400
0~500 		2.5 320-420 22mm
Type Capillary tube length(m) Temperature bulb and capillary tube material Maximum length of capillary tube
Normal type 1~20 T2 20
Anti-corrosive type 1~10 1Cr18Ni9Ti 15
