10-30kw Marine generator

Request a Quote Not what you need, please send your RFQs via Email.

Details

10-30kw Marine generator

General features:

  • Coupled with Yangchai diesel engine and Sunvim alternator
  • 24V DC start motor
  • Brushless, Self-excited, AVR, insulation Class H alternator

Criteriron:

GB/T13032-1991

ISO9001:2008 Quality Control System

Engine Specification

Engine Model:WP2.5CD22E1

Cylinders: 4 Cylinders in line

Cycle: 4 stroke

Aspiration: Turbocharged

BorexStroke: 90x100mm

Displacement 2.5L

Prime power/speed: 22kw/1500rpm

Speed governor: Mechanical

Cooling system: Water-cooling

Fule consumption at 100% load: 197g/kw.h

Starter motor: DC24V

Sunvim Alternator(Standard):

Alternator Model: SVH184

Prime power: 20kw

Frequency/speed: 50hz/1500rpm

Exciter type: Brushless, self-excited

Power factor: 0.8

Insulation grade: H grade

Protection grade: IP23

Phase/wire: 3 phase/3wires
